Explosion proof gas box pulse bag filter is a bag filter that combines explosion-proof technology with gas box pulse dust cleaning method, mainly used to treat dust in flammable and explosive environments. It not only has efficient dust removal capabilities, but also ensures safe and stable operation in hazardous environments through special design and material selection.

Basic structure and composition

The explosion-proof gas box pulse bag filter mainly consists of the following parts:

Explosion proof enclosure: Adopting a special design, it can withstand a certain internal pressure and prevent explosions caused by dust accumulation.

Filter bag: Select materials that are resistant to high temperatures and corrosion to ensure that the filtering performance can still be maintained in harsh environments.

Pulse cleaning system: including a pulse electromagnetic pulse valve, used to control the injection of compressed air, causing vibration and deformation of the filter bag, thereby removing dust attached to the surface of the filter bag.

Ash discharge device: such as star shaped ash discharge valve or screw conveyor, used to discharge collected dust.

Working principle

After the dust containing gas enters the dust collector, it first passes through the guide plate to evenly distribute the airflow and guide it to the filter bag chamber. In the filter bag chamber, dust is trapped on the outer surface of the filter bag, and purified gas is discharged through the pores of the filter bag. As the dust removal process progresses, the dust on the surface of the filter bag gradually increases, leading to an increase in the resistance of the filter bag. When the resistance reaches the preset value, the pulse cleaning system starts working. The explosion-proof electromagnetic pulse valve controls the injection of compressed air, causing the filter bag to produce instantaneous vibration and deformation, thereby shaking off the dust attached to the surface of the filter bag.

Application scenarios

Explosion proof gas box pulse bag filter is widely used in the following scenarios:

Coal mining industry: used to deal with coal dust generated in coal mining production, reduce the release and diffusion of coal dust, and lower the risk of fire and explosion.

Chemical industry: Handling various harmful gases and flammable and explosive substances to ensure production safety.

Cement production: Remove dust during the cement production process to protect the cleanliness and safety of production equipment and working environment.
